Блок питания лабораторный KORAD KA3010D

Model

KA3010D

Voltage Range / Current Range

0-30V  /  0-10A

Load Regulation

Voltage: ≤0.01%+2mv  /  Current: ≤0.1%+5mA

Line Regulation

Voltage: ≤0.01%+3mv  /   Current: ≤0.1%+3mA

Setup Resolution

Voltage: 10mV   /     Current: 1mA

Setup Accuracy（ 25 ℃ + - 5 ℃ ）

Voltage: ≤0.5%+20mV   /   Current: ≤0.5%+10mA

Ripple(20hz-20M)

Voltage: ≤2mVrms    /    Current: ≤5mArms

Temp. Coefficient

Voltage: ≤100ppm+10mV  /  Current: ≤100ppm+5mA

Read Back Accuracy

Voltage: 10mV   /   Current: 1mA

Read Back Temp. Coefficient

Voltage: ≤100ppm+10mv   /   Current: ≤100ppm+5mA

Reaction Time(10% Rated load）

Voltage: ≤100mS   /   Current: ≤100mS

Operation Environment

Indoor use
Altitude: ≤ 2000m
Ambient temperature 0 ~ 40°C
Relative humidity ≤ 80%

Interfaces

Optional Interfaces (for programmable models only): RS232, USB

Accessories

User manual, Power cord (1.2M),
USB cord (1.2M;  for programmable models only)

Weight and Dimension

7 kg  /  110(W)*156(H)*310(D)

Storage Environment

Ambient temperature   –10℃ ~ 70℃
Relative humidity       ≤ 70%
